Description
-
The supporting arm can be adjusted based on glass dimension.
-
The support device is equipped with vacuum chuck. So no manual holding is needed on spreading.
-
Operators are capable to operate the footswitch for control the lifting and rotating of glass about the 0~90 degree rotation as to complete sealing of glass edge.
-
The machine is simple in operating procedures and high in working efficiency.
Equipment parameters
| Item. | Spec. |
| Air pressure | 0.5~0.8MPa |
| Rotation speed | 4r/min |
| Power supply | 380V 50Hz |
| Total power | 0.37Kw |
| Motor power | 0.12Kw |
| Operating dimension | 1500mm*1500mm |
| Dimension | 600mm*550mm*985mm |
| Min. glass size | 175mm*175mm |
